詳細情報 |
|||
| 学年: | AISI 430 / UNS S43000 / SUS430 | タイプ: | フェライト系ステンレス鋼板（DDQ） |
|---|---|---|---|
| 厚さ: | 0.4mm～1.5mm | 幅: | 1000mm、1219mm、1250mm |
| 長さ: | 2000mm、2438mm、3000mm、カスタマイズされた | 表面仕上げ: | BA（光輝焼鈍）、2B |
| 状態: | 完全焼鈍、軟質焼戻し | 応用: | 深絞り、スタンピング、プレス成形、調理器具、シンク |
| 技術: | 冷間圧延、光輝焼鈍 | 伸長: | ≥ 22% |
| 試験報告書: | エリクセン カッピング テスト、MTC EN 10204 3.1 | ||
| ハイライト: | Deep Drawing 430 Stainless Steel,Stamping Grade 430 SS Sheet,430 Formable Stainless Steel Plate |
||
製品の説明
This 430 stainless steel sheet is specifically produced for deep drawing, stamping, and press forming operations. Processed in the fully annealed condition with a bright annealed (BA) finish, it delivers optimal elongation, reduced springback, and excellent surface quality for complex formed parts.
- High Elongation: Elongation rate ≥ 22% ensures excellent ductility for deep drawing and complex stamping without cracking
- Full Annealed Condition: Softened microstructure maximizes formability and minimizes work hardening during multi-stage forming
- Low Yield Strength: ≥ 205 MPa yield strength provides easy deformation with reduced press tonnage requirements
- Excellent Surface Quality: BA (Bright Annealed) finish provides a smooth, defect-free surface ideal for post-forming finishing
- Uniform Grain Structure: Consistent metallurgical properties across the entire sheet ensure predictable forming behavior
- Reduced Springback: Ferritic structure offers lower springback compared to austenitic grades for better dimensional accuracy
- Kitchen sink bowls and sink basins (deep drawn)
- Cookware bodies, pots, and pan blanks
- Automotive body panels and stamped trim parts
- Appliance housings and washer/dryer drums
- Electrical enclosure boxes and junction boxes
- Metal furniture components and chair shells
- Industrial filter housings and containers
| Grade | AISI 430 / UNS S43000 / DIN 1.4016 / JIS SUS430 |
|---|---|
| Type | Ferritic Stainless Steel (Deep Drawing Quality) |
| Chromium Content | 16.00 - 18.00% |
| Carbon Content | ≤ 0.12% (Low Carbon for Formability) |
| Thickness Range | 0.4mm - 1.5mm |
| Standard Width | 1000mm, 1219mm, 1250mm |
| Surface Finish | BA (Bright Annealed), 2B |
| Condition | Full Annealed, Soft Temper |
| Tensile Strength | ≥ 450 MPa |
| Yield Strength | ≥ 205 MPa |
| Elongation | ≥ 22% |
| Hardness | ≤ 88 HRB |
| Grain Size | ASTM 5-8 (Fine Grain) |
The material undergoes vacuum degassing (VOD) during melting to control inclusion levels, followed by continuous casting, hot rolling, cold rolling to final thickness, and a bright annealing process in a controlled atmosphere furnace to achieve optimal formability and surface quality.
Every shipment includes an Ericsen cupping test report and mechanical property certification (MTC EN 10204 3.1). We can also provide forming simulation data and technical support for your specific die design requirements.
Sheets are protected with laser-grade PE film, interleaved with protective paper, and packed on fumigated wooden pallets. Standard delivery within 7-15 working days.
Request a quotation and forming sample today — our technical team can assist with material selection for your specific deep drawing application.
